• channels 4 - 3 - 2
• POWER SUPPLY
  • Supply voltage / fuse: 11 - 15 VDC / 2 x 35 A
  • Idle current (on/off) 1.6 A / 0.05 mA
  • Consumption @ 2 Ω, 14.4 VDC (Maximum musical output): 40 A
  • Remote input: 4 - 16 VDC - 1 mA
  • ART: Remote automatic power on/off with speaker-in
• AMPLIFIER STAGE
  • Distortion - harmonic distortion (100 Hz @ 4 Ω): 0.03%
  • Bandwidth: 10 - 35k Hz
  • Signal to noise ratio (A weighted @ 1 V): 105 dB
  • Attenuation factor (100 Hz @ 4 Ω): 200
  • Pre-in sensitivity: 0.2 - 5 VRMS
  • Speaker input sensitivity: 0.8 - 20 VRMS
  • Load impedance (MIN)
    • @ 4 channels: 2 Ohm
    • @ 3 channels: 2 Ohm + 2 Ohm + 4 Ohm
    • @ 2 channels: 4 Ohm
  • Maximum size (mm): 315 x 190 x 50
  • Weight (kg): 2,73
  • Adjustable crossovers yes

Output power

• Output power (RMS) @ 14.4 VDC, distortion 1%.
  • 4 channels: 120W x 4 (4 Ω)
  • 4 channels: 220W x 4 (2 Ω)
  • 3 channels: 120W x 2 (4 ohms) + 440W x 1 (4 ohms)
  • 3 channels: 220W x 2 (4 ohms) + 440W x 1 (4 ohms)
  • 2 channels: 440W x 2 (4 Ω)
• Output power (RMS) @ 14.4 VDC, distortion 10%:
  • 4 channels: 150W x 4 (4 Ω)
  • 4 channels: 250W x 4 (2 Ω)
  • 3 channels: 150 W x 2 (4 ohms) + 520 W x 1 (4 ohms)
  • 3 channels: 250W x 2 (2 ohms) + 520W x 1 (4 ohms)
  • 2 channels: 520W x 2 (4 Ω)
• CEA 2006-A ratings:
  • RMS power (4 Ω, ≤1 % THD + N, 14.4 V): 110 W x 4 channels.
  • Signal-to-noise ratio (ref. 1 W power): 85 dBA.
• Total power RMS 2000 watts

Input / Filter

• INPUTS: PRE IN / SPEAKER IN
• Pre out FULL range (FRONT) Yes
• FRONT Ch. Filter FULL Yes
  • Hi-Pass: 50 - 3.2k Hz @ 12 dB/Oct
  • Lo-Pass: 50 - 3.2k Hz @ 12 dB/oct.
• REAR channel filter FULL: Yes
  • Hi-pass: 50 - 3.2k Hz @ 12 dB/oct.
  • Lo-Pass: 50 - 3.2k Hz @ 12 dB/oct.
• FRONT Ch. MONO (on/off): Yes
• REAR Ch. MONO (on/off): Yes
• BOOST 50 Hz (adjustable): (0 - 12) dB
